The Normal Mode is adjusted by default. In this mode, which is displayed by the Cue LED, it is possible to control all general
deck features.
Jog (18)
paDs (15)
Drehrad
By pressing the Track Encoder, Browser Mode can be maximized and minimized respectively. This allows a much more comfor-
table track navigation.
In this mode the Jog Wheel and a few other elements work differently.
Jog (18)
track rad (4)
Folder
Search
tasten (6)
CC-ABSOLUTE (VR)
Control Change messages are sent with status 0xBn, where n is the channel, for the specified CC controller. Thus the con-
troller MIDI ID is indicated with the channel along with the CC number. The value from 0x00 to 0x7F, directly related to the
location of the controller.
CC-RELATIVE (ENC)
Control Change messages are status 0xBn, where n is the channel, for the specified CC controller. Thus the controller MIDI ID
is indicated with the channel along with the CC number. The value from 0x40 to indicate the change in the controller. This is
an offset to 0x40 "one's complement" notation.
A message with data 0x43 indicates a positive change of 3.
A messages with data 0x31 indicates a negative change of 15.
SWITCH ON/OFF (SW,CENTER,CW,CCW)
These messages are used for switches.
Control Change messages are sent with status 0x9n, SWITCH On and Off value are 0x7F and 0x00, where n is the channel.
LED ON/OFF (LED)
These messages are used for LED.
Control Change messages are sent with status 0x9n, LED On and Off value are 0x7F and 0x00, where n is the channel.
PITCHBEND
Pitchbend messages are status 0xEn, where n is the channel, for the specified controller.
Thus the controller ID is indicated only by the channel.
For accurate changes, the 14 bit data in a pitch bend message is reserved for absolute controllers which require more than 7
bits of data.
36
VarIOuS MODES (NOrMaL/BrOWSEr/EFFECt)
track
(4)
Normal Mode
• When turning the Jog Wheel without an activated Jog Wheel function, the
speed of the selected track will be changed temporarily
• If the Scratch Button has been pressed the Jog Wheel can be used for scrat-
ching. Please observe that this feature is only available when the Jog Wheel
platter is being touched.
If a PAD Button (1-4, + Shift: 5-8) is pressed the track will jump to the saved
Cue Point, if one is set. The track will
Be re-played from the same position when the button is being pressed again.
If no Cue Point has been set, pressing the Hot Cue Buttons has no effect.
PAD button assignment:
• By turning the Track Encoder it is possible to navigate through Track List View.
• Shift + turning the Track Encoder allows Tree View navigation. Please consider that
the Folder Search Buttons (6) can be used for the same function in Normal Mode.
Search-Tasten (6) für die gleiche Funktion im Normal Modus verwendet werden
können
• If a larger Track/Tree View is desired, >Browser Mode should be activated.
Browser Mode
- By turning the Jog Wheel it is possible to navigate through your music collection.
- If the Jog Wheel is in X Parameter Mode (25) it is possible to navigate through
Tree View by moving the Jog Wheel
- If the Jog Wheel is in Y Parameter Mode (26), it is possible to quickly navigate
through your music collection
Tree View navigation by turning the Track Encoder.
Selected folders can be opened and closed in Tree View by pressing the Folder
Search Buttons (6).
