• When disposing of batteries, they
must be discharged or their capacity
must be fully depleted. Cover exposed
terminals with adhesive tape in order
to prevent short-circuiting!
Maintenance and care:
• Please only use a clean, damp cloth
to wipe off the model.
• Protect the model and batteries from
direct sunlight and/or direct heat.
• Never allow the remote control and
charging unit to come into contact
with water, because the electronics
will be damaged as a result.
Technical changes and differences in
color reserved!
1 QUADROCOPTER
1A Rotors 1D Lens
1B Motor 1E Connection cable
1C Landing skid 1F Battery compartment

2 REMOTE CONTROL

2A Controller for thrust and rotation
2B Trim for rotation
2C ON/OFF switch
2D Trim for forwards and backwards flight
2E Trim for banking
2F Control for forwards/backwards and
sideways
2G Display
18
Required batteries for the
quadrocopter:
Power supply:
Rated output: DC 7,4 V / 4,51 Wh
Batteries: 1 x 3,7 V rechargeable
LiPo battery (included)
Capacity: 610 mAh
Battery requirement for the remote
control:
Power supply:
DC 6 V
Batteries: 4 x 1.5 V "AAA"
(not included)
USB charger:
Power supply:
DC 5 V via a 500 mA or higher USB port
Rated output: 5 V / 500 mA max.
1G Micro-SD card slot
1H USB socket
(for service only)
2H Battery compartment locking screw
2I Battery compartment cover
2J Button for Return to Home function
2K Photo/video button
2L Battery compartment securing screw
2M Battery compartment
3 DISPLAY OF REMOTE CONTROL
3A Satellite display
3B Number of satellites
3C Remote control battery condition
3D Video symbol
3E Photo symbol
3F Model battery condition
3G „Viewing direction" of the model in de-
grees (N=0°, E=90°, S=180°, W=270°)
3H „Set Compass" symbol
4 INSERTING BATTERIES (REMOTE CONTROL)
4A Unscrew and remove 4B Insert 4 x 1.5 V AAA
the cover.
batteries and pay attention
to the polarity, as shown in
the battery compartment.
5 CHARGING THE MODEL
Attention: The battery and motor must cool down for 10 to 15 minutes before
charging and after every flight. Otherwise they can be damaged. The charging process
must be constantly monitored. Always ensure that the charging process takes place on
a fireproof surface in a fire-resistant environment.
• Unplug the model from the battery and switch off the remote control.
• Remove the battery from the battery compartment (do not pull by the cable!).
• Insert the white battery plug into the charging socket of the charger, making sure that
the polarity is correct. The battery must be gently inserted into the charging socket –
DO NOT USE FORCE. If the battery is not correctly inserted into the charging socket,
the battery may become damaged and, under certain circumstances, cause injury.
The charger flashes.
• The charging process starts automatically and must be continuously monitored.
The charger flashes slowly during the charging process. (quick flashing indicates a
malfunction – the charging process must be stopped immediately.) As soon as the
charging process is complete, the charger lights up continuously.
• Disconnect the battery from the charger and disconnect the charger from the USB
port once charging is complete.
After a charge time of approx. 80 minutes the model can fly for
approx. 10 – 12 minutes.
Warning notice: The battery does not normally heat up while charging. If it should
become warm and/or changes to the surface begin to appear, immediately discontinue
the charging process!
3I Expert symbol
3J Mode 1/2 display
3K Altitude of the model (relative to the
starting point)
3L „Altitude" symbol
3M Distance of the model (relative to the
starting point)
3N „Distance" symbol
4C Close the battery
cover and secure
with the screw.
