11 FLIGHT CONTROL (MODE 2)
Note: Only minimal corrections of the controls are necessary for a smooth flying behaviour
of the model! The direction indication applies when the model is viewed from behind. If
the model is flying towards the pilot, it must be moved in the opposite direction.
11A Take off or increase altitude by carefully moving the control for thrust and rotation
forward.
11B Land or decrease altitude by moving the control for thrust and rotation backward.
11C Fly forward by moving the controller for forward/backward and sideways flight
carefully forward.
11D Fly backward by moving the controller for forward/backward and sideways flight
carefully backward.
11E Fly to the left by moving the controller for forward/backward and sideways flight
carefully to the left.
11F Fly to the right by moving the controller for forward/backward and sideways flight
carefully to the right.
11G Turn the model around to the left by moving the control for thrust and rotation to the left.
11H Turn model around to the right by moving the control for thrust and rotation to
the right.
HEADLESS MODE
When Headless Mode is activated, the model reacts to control commands, as though
the tail of the model always faced the pilot, regardless of the direction of the model.
Therefore, it can also be controlled ‚normally' without thinking.
By pressing the controls for forwards/backwards and sideways (2F) Headless Mode
can be switched off and on.
Attention: To function correctly, Headless Mode must be activated when the tail of
the model is pointing directly towards the pilot.
GPS RETURN-TO-HOME FUNCTION
This function moves your model back to its start position (the place where you started
the motors). Here your model will first rise or fall to an altitude of approx. 10 m, return
to its start position and land.
By pressing the button for the Return to Home function (2J) the GPS Return to Home
function can be switched on and off. Any movement of the two controls (2A) and (2F)
ends the Return to Home function and the model can be normally controlled again.
Important! Always keep your model in view and the transmitter in your hands – you
must be able to avoid any obstacles immediately at any time. Having the model fly
alone via GPS without continuous visual checks by the pilot is against the law!
22 22
12 CAMERA FUNCTION
The model has a camera for photos and videos and a slot for MicroSD cards.
Disconnect the model from the battery before inserting or removing a MicroSD card.
If the MicroSD card is inserted correctly, the model is connected correctly and a connec-
tion with the transmitter is in place, a blue LED lights up next to the card slot (1G).
Photos: briefly press the photo/video button to take a photo. The transmitter beeps
twice, the LED next to the MicroSD card slot briefly lights up red and the photo symbol
on the display (3E) briefly flashes.
Videos: hold the photo/video button to record a video. The transmitter beeps once,
the LED next to the MicroSD card slot flashes red and the video symbol on the display
(3D) briefly flashes. Hold the photo/video button again to end the recording.
Note: No photos can be taken while a video is being recorded. To download the data
from the SD card please follow the instructions of your operating system.
13 CHANGING THE PROPELLERS
Prior to installation, make sure that you do not mix up the propellers. The model
has 4 different propellers, which differ in color and direction of rotation. If the
propellers are mixed up, the model will not fly.
13A Arrangement of the propellers:
front left grey B
rear left black A
13B Loosen the screw in the centre of the propeller and pull it off the shaft.
13C The shaft has a flat point on its side. The propeller has a matching catch on the
inside (see marking, 11C). Position the new propeller on the shaft in such a way
that the marking is covered by the flat point. Firmly retighten the screw.
front right grey A
rear right black B
