T E C H N I C A L D A T A A N D A C C E S S O R I E S / S P A R E P A R T S
11 Technical Data and Accessories/Spare Parts
E N
Subject to changes.
Technical data of the milling machine
Art. No.
Dimensions
(D × W × H)
Weight:
Electrical connec-
tions
Power output
Fuse (time-delayed)
Axes
Accuracy
Allowable tempera-
ture range (opera-
tion)
Spindle torque
Spindle speed
Collet diameter
Sound pressure
level
Interfaces
Max. pump flow
rate
Tab. 3
68
Unit Value
–
179250-IDC
650 × 570 × 740
mm
75 - 78
V/Hz 100-230/50-60
W 750
A 3.15 / 6.3
4 - 5
μm < 10
°C
18 - 30
Ncm 9.2
rpm 100,000
mm 3
dB(A) 60
–
USB / Ethernet /
slot for SD card /
controlling of
supply unit /
controlling of
extraction
l/min 3.8
Compressed-air
connection
_ Pressure
_ Flow rate
Air purity
_ Solid contami-
nants
_ Water content
_ Total oil content
Extraction
_ Diameter of
extraction con-
nection
_ Suction capacity
Tab. 3
Unit Value
–
Dry, clean com-
pressed air
bar 6
l/min 50
–
Class 3;
better than
5 μm for solids
–
Class 4;
Max. pressure
dew point
+3 °C
–
Class 2; max.
oil content
3
0.1 mg/m
–
Suitable for zir-
conium oxide
dust particles,
HEPA microfil-
ter (97.97 %), fil-
ter class H12,
dust category M
mm 38
3
m /h 240
