CONNECTION OF THE FEEDING CABLE TO THE MAINS
Connect the feeding cable to a plug suitable for the load indicated on the rating
plate of the product. In case of a direct connection to the mains (cable without
plug), it is necessary to insert a suitable omnipolar switch before the appliance,
with minimum opening between contacts of 3 mm (the grounding wire should not
be interrupted by the switch).
Before connecting to the main electrical wiring, make sure:
• The electrical counter, the safety valve, the feeding line and the socket are
equipped to withstand the maximum load required to run the range. (see
rating plate).
• The supply system is regularly grounded, according to the local regulation
codes.
• The socket or the omnipolar switch can easily be reached after the
installation of the range.
• After carrying out the connection to the main electrical wiring, check the
supplying cable does not come into contact with parts subject to heating.
• Never use reductions, shunts, or adaptors which can cause overheating or
burning.
The manufacturer is not liable for any direct or indirect damage caused by
faulty installation or connection. We recommend all installation and connection
operations be carried out by qualifi ed personnel complying with the national and
local regulation codes.
CAUTION
Connect the black wire to the N (neutral) tab; connect the red wire to the L (live) tab
and the green or green/yellow wire to the ground tab. Do not swap connections.
Model
RFA-244 DF
RFA-365 DF
ELECTRICAL SPECIFICATIONS
Volts
240
240
14
Watts
2.5 KW
3.55 KW
Amps
15
15
