For a situation where the appliance is between two cabinets and the anti-tip
device cannot be fi tted, we suggest securing the range by screwing through
both sides of the cabinets into the sides of the cooker. The installation screws
should be fi tted as follows. Position the oven between the cupboards in its fi nal
position, then mark the location of the pilot hole inside the cupboard. Use a
3.5mm diameter drill bit to drill the pilot hole through the cupboard and both
sides of the range.
Before drilling, check your measurements to ensure the pilot holes are located
within the area specifi ed in the installation diagram. A drilled hole in the side of
the range, which is outside the specifi ed area, may void the warranty. Inspect
cabinets thoroughly before drilling to avoid damage to electrical wires or gas
lines. Fix two 12 gauge x 40mm long self tapping screws through the pilot holes
inside both cabinets and into the side of the range.
Note: Required screw length is based on cupboard thickness of 20mm, and gap
between cupboard and range of 10mm.
Screw length could vary depending on cupboard material thickness and gap
between range and cupboards.
Note: The screws must be accessible for removal.
2.4

ELECTRICAL CONNECTION

WARNING! ELECTRICAL SHOCK HAZARD
Disconnect electrical power at the breaker box or fuse box before installing
this appliance. Please make sure the unit is properly grounded for safety.
Use copper conductors only. Failure to follow these instructions could
result in serious injury or death.
CAUTION
Label all wires prior to disconnecting when servicing controls. Wiring
errors can cause improper and dangerous operation. Always verify proper
operation after servicing.
The range is fi tted with an approved 15 Amp fl exible cord which must be
connected to a correctly grounded power line. The manufacturer is not liable
for any direct or indirect damage caused by faulty installation or connection. It
is therefore necessary that all installation and connection operations are carried
out by qualifi ed personnel complying with the applicable local and general
regulations.
The wire section on the cable must not be less than 1.5mm (3×1.5 cable). Use
only the cables available at our service centers.
