BH FITNESS S5RiB Recumbent Guide D'utilisation page 16

STEP 3
53
Thread the Left Pedal (53) into the
left crank arm counter clockwise.
Then screw the Right Pedal (48)
into the right crank arm clock wise.
48
STEP 4
Slide the Post Cover (56) onto the
64 - 6pcs
Post Tube (55) then connect the
cables from the Post and Frame.
65 - 6pcs
Then mount the Post Tube (55)
onto the frame. Secure with Allen
screws (64) and Curved washers
(65) and slide the post cover down
into place.
16
