IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS
Caution! Non-compliance can result in serious injury. Observe
EN 60 335-2-97 Safety Instructions in full.
Any work on the electrical installation may only be performed by a
qualified electrician.
All the standards and regulations applying to electrical installa-
tions must be observed.
When electrical or electronic systems and appliances are in opera-
tion, certain components are live, which can constitute a risk. Any
touching of and work performed on the equipment by persons
not qualified to do so or non-compliance with safety instructions can
result in personal injury or damage to property.
Neither the manufacturer nor the supplier assumes any liability for
personal injury, damage to property or consequential injury or dama-
ge occurring as a result of the use of non-approved third party
products or changes made to any accessories.
Notice:
a. do not store motor with strong acid and alkali or dirty and eroding
materials.
b. do not use motor in humid or damp environment.
c. do not use motor for public buildings or garage doors.
d. do not run motor at maximum capacity; this might reduce
durability.
e. do not turn adjustment screws or adapter parts when motor is
switched off.
f. if manual operation of the shutter system is required have a
qualified electrican install CRXN type of motors.
The actuating part of the manual release is to be installed at a
height of less then 1.8m.
Ensure that the motor is accessible after installation.
H05VV-F of the motor power can only be used for indoor installati-
ons use, H05RR-F rubber power can be used in outdoor installation
black ordinary tough rubber sheathed cord (60245 IEC 53) is suita-
ble alternative cable for outdoor use, provided that sheath contains
at least 2 % of carbon in accordance with the tests of clause 11 of
IEC60811 4 1.
This operators' power cable must only be replaced by the same type
of cable delivered by the manufacturer of the cable.
To reduce the risk of danger a defective power cable must be
replaced by the manufacturer, the manufacturers' service or a similar
qualified person.
Check shutter or sun-blind system regularly for signs of wear and
damage. Damaged systems should not be used under any cir-
cumstances until such time as they have been repaired.
Observe shutter or sun-blind system carefully whilst in operation.
Switch off shutter or sun-blind system and disconnect from
mains supply, if any servicing or cleaning has to be done either
on the system itself or in its immediate vicinity.
WARNING: the drive shall be disconnected from its power
source during cleaning, maintenance and when replacing parts.
Frequently examine the installation for imbalance and signs
of wear or damage to cables springs and fixings. Do not use if
repair or adjustment is necessary
Do not operate when maintenance, such as window cleaning, is
being carried out in the vicinity.
Before installing the drive, remove any unnecessary cords or
components and disable any equipment not needed for powe-
red operation
Disconnect the drive from the supply or switch off the automa-
tic controls when maintenance, such as window cleaning, is
being carried out in the vicinity.
Only those spare parts, tools and other equipment as have been
approved by Chamberlain may be used.
Prior to performing installation work, deactivate all connections and
control facilities that are not absolutely essential for operation of the
given system.
Moving parts of the operator must be installed at a height of more
than 2.5m above floor or another floor level which allows access
to the operator. The A-weighted emission sound pressure level of
the drive is equal to or less than 70 dB(A), e.g. by writing LpA ≤ 70
dB(A).
Fit control facilities within sight of the product to be controlled at a
height of at least 1.5 m.
A disconnecting device must be provided in the permanently-wired
installation to guarantee all-pole disconnection by means of a switch
(at least 3mm contact gap) or by a separate fuse.
Torque rating and duty cycle must comply with the requirements of
the product to be driven.
Technical data - torque rating and duty cycle details can be found on
the tubular drive's data plate.
Ensure system cannot trap or cut persons and secure relevant
parts. Observe safety margins as stipulated in DIN EN 294. Ensure
sufficient room (at least 40 cm) is left between any moving parts and
nearby objects.
Please consult Chamberlain product information for further details.
Children should be supervised to ensure that they do not play with
the appliance. Do not allow children to play with the controls. Do not
allow children to play with fixed controls. Keep remote controls away
from children.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Cleaning and user
maintenance shall not be made by children without supervision.
Before You Begin:
1. Carefully read all the information contained in this Owner's
Manual before beginning installation procedures.
2. Check the shutter to be sure it is not broken or damaged, and
that it opens and closes smoothly.
3. Determine whether the motor needs to be installed on the left
side (a) or the right side, (b) of the shutter – Figure E. Always
choose the shortest possible distance to the next junction box as
wires must not be laid inside the shutter box.
4. Ensure that the motor can be pushed in as far as the stop. The
limit switch is controlled by the plastic ring which must be
pushed fully on.
