US English User Manual for RAIS Rondo, RAIS Mino II and RAIS Mino II Soapstone
12
Clearance to combustible walls
To find out whether the wall by which the stove is to be placed is
combustible or not, please contact your architect or the local building
authorities.
If the floor is combustible, the stove must be placed on a non-com-
bustible plate such as steel, glass or stone.
Ref. Description
A Sidewall to unit
B Backwall to unit
C Cornerwall to unit
D Sidewall to connector
E Backwall to connector
F Cornerwall to connector
G Ceiling to appliance
H Backwall to unit
I Backwall to connector
J Sidewall to unit
K Sidewall to connector
L Distance to frontwall/furnishing
M Cornerwall to connector
Clearance to non-combustible wall
We recommend a minimum clearance to non-combustible material of
at least 50 mm so that cleaning is easy. The cleaning door should be
accessible at all times.
Clearances may only be reduced by means approved by the regulatory
authority.
Minimum clearence
13" (33 cm)
6.5" (16.5 cm)
6" (15.2 cm)
20" (50.8 cm)
12" (30.5 cm)
14" (35.6 cm)
43,5" (111 cm)
13" (33 cm)
20" (50,8 cm)
34" (86,4 cm)
41" (104 cm)
34" (86.4 cm)
41" (104 cm)
**:
Please refer to NFPA guide-
lines in USA and CAN/CSA
B365-M91 in Canada.
