GB
OMNIA HL C - HL CM FANCOIL
The OMNIA HL (High Line) fancoil, with its characteristic
design by Studio Giugiaro, offers an array of technical featu-
res that make it the ideal climate-control unit for all types of
applications.
Treated air is immediately delivered to the entire room;
the OMNIA HL produces warm air when fitted to a heating
system with boiler or heat pump, but can also be used
during the summer season as an air-conditioning unit (if the
main system is also equipped with a water chiller).
The quality of processed air is guaranteed by a special
electrostatically pre-charged filter that absorbs and traps
suspended dust particles (when the unit is off, a closed lou-
ver prevents dust and other foreign particles from entering
the unit interior). The removable drip tray and fan volute
ensure thorough cleaning of the unit (by specifically trained
personnel), essential for installations in venues subject to
crowding or in those with special hygiene requirements.
The new centrifugal fan assembly is so quiet that during
VERSIONS:
HL C RAL9002 white body with on board electronic thermostat. The air distribution head and the skirts are in RAL7044.
HL CM FIAT656 metallic grey body with on board electronic thermostat. The air distribution head and the skirts are in
RAL7031 grey.
RED/BLUE/PINK LED (C)
- Displays the operating mode -
HEATING or COOLING - currently
requested by the electronic thermo-
stat and whether the heating system
is able to satisfy the request.
SELECTOR (A)
- On/Off
- Automatic operation
- Manual speed selection
12
standard operation it's virtually impossible to hear when the
OMNIA HL starts up. And the use of electronic control
panels eliminates the annoying noises typical of mechanical
thermostats.
The control panel with electronic thermostat is protected
by a panel on the unit head.
Electronic temperature control, automatic fan speed swit-
chover, automatic season switchover and start-up - automa-
tic shutdown (version with thermostat).
With its large range of accessories, the OMNIA HL fancoil
is designed to satisfy all installation types.
The unit can be easily installed either vertically or hori-
zontally (water connections can be reversed as required
during installation).
Full compliance with safety regulations.
Routine maintenance is limited to periodic cleaning of the
air filter in water.
WHITE LED (D)
- Indicates ventilation request by the
electronic thermostat.
SELECTOR (B)
- Selection of required room tempera-
ture.
