GB
I N S T A L L A T I O N A N D O P E R A T I N G I N S T R U C T I O N S
Application
The Flamco Clean can be used in heating/cooling systems
(with glycol-based additives, max. 50%).
Safety
Min./max. system temperature –10 °C to +120 °C.
Min. system pressure at the Flamco Clean 0.2 bar.
See the label for the maximum permissible working pressure.
Max. speed through the Flamco Clean 1.5 m/s.
Construction/installation Install the Flamco Clean in a dry location not susceptible to frost which is easily
accessible for maintenance purposes.
Install the Flamco Clean directly before the boiler, in the return pipe, ideally before
the circulation pump (fi g. 1).
Make sure installation is performed by qualifi ed personnel only.
Local legislation & guidelines must be observed at all times.
Flush the installation thoroughly before fi tting the Flamco Clean.
The Flamco Clean must be fi tted vertically (fi g. 2).
In order to promote good blowing down, we recommend fi tting valves before and
after the Flamco Clean (fi g. 3).

Maintenance/service

The Flamco Clean must be visually inspected regularly.
Dirt that collects in the Flamco Clean's dirt trap can be fl ushed out using the drain
cock (fi g. 3). Only fl ush when the system has been de-pressurized and has cooled
down. On types DN 50 - 600, stubborn dirt can be loosened by turning the tap
anticlockwise (fi g. 3). Servicing may only be carried out when the system has been
de-pressurized and has cooled down. Never use the drain cock for fi lling (fi g. 4).
Removal
De-pressurize the system and remove the Flamco Clean from the system.
Local legislation must be adhered to when disposing of the Flamco Clean.
