Pag. 18 di 28
D - TIME PROGRAMMING FOR TWO MOTORS (#)
E
N
WITH ELECTRIC LIMIT SWITCHES (IF APPLIED) (DIP 7 OFF AND JUMPER S3
CLOSED)
G
1 - Start with the gate completely closed.
L
2 - Put DIP 2 in the ON mode => LED DL9 will blink rapidly.
3 - Press PROG. => M1 opens.
I
4 - When the gate comes into contact with the opening electric limit switch, it stops M1
S
and M2 starts to open simultaneously.
5 - When the gate comes into contact with the opening electric limit switch, it stops M1 =>
H
the delay countdown prior to automatic closing starts simultaneously (max 5 minutes).
6 - Press PROG. => delay countdown prior to automatic closing stops and M2 closes.
7 - Press PROG. => M1 closes and creates a phase difference between M2 and M1. At
the same time LED DL9 stops blinking to signal exit from the programming mode.
At this point, the safety devices and other gate controls will resume normal operation
(inversions, stops, alarms, etc.).
9 - When the gate comes into contact with the closing electric limit switches, it will stop.
10 - AFTER PROGRAMMING, SWITCH DIP 2 TO OFF.
TIME PROGRAMMING FOR ONE MOTOR (#)
IMPORTANT: CUT OUT S2 TO OPERATE ONE MOTOR.
WITH ELECTRIC LIMIT SWITCHES (IF APPLIED) (DIP 7 OFF AND JUMPER S3
CLOSED)
1 - Start with the gate completely closed.
2 – Put DIP 2 in the ON mode => LED DL9 will blink rapidly.
3 - Press PROG. => M1 opens.
4 - When the gate comes into contact with the opening electric limit switch, it stops M1
and the delay countdown priot to automatic closing starts (max 5 minutes).
5 - Press PROG. => delay countdown prior to automatic closing stops and M2 closes.
At the same time LED DL9 stops blinking to signal exit from the programming mode.
At this point, the safety devices and other gate controls will resume normal operation
(inversions, stops, alarms, etc.).
6 - When the gate comes into contact with the closing electric limit switch, it will stop.
7 - AFTER PROGRAMMING, SWITCH DIP 2 TO OFF.
(#) SAFETY DEVICES ARE ACTIVE DURING THE PROGRAMMING AND THEIR
INTERVENTION STOPS IT (THE LED 9 BLINKS NO MORE BUT REMAINS
CONSTANTLY TURNED ON).
TO REPEAT THE PROGRAMMING, POSITION DIP1 AND 2 ON MODE OFF, CLOSE
THE GATE AND REPEAT THE PROCEDURE DESCRIBED ABOVE.
OPERATION OF THE OPERATING ACCESSORIES
OPENING BUTTON (with timer function)
When the gate is standstill, the button operates the opening mode. If you push this button
when the gate is on closure, It opens again.
TIMER FUNCTION
This function is useful In the rush hours, when vehicle traffic is slow (e.g. entry/exit of
workers, emergencies In residential or parking areas and, temporary, for removals).
APPLICATIONS
By connecting a switch and/or a daily/weekly timer (in place or in parallel with the opening
button N.O. "COM-OPEN"), it is possible to open the automation or to keep It open, as
long as the switch is on or the timer is activated.
When the automation is open, all operating functions are inhibited.
If the automatic closing Is started, by releasing the switch or at the time set before, the
automation immediately closes; if not, you need to operate a command.
CLOSING BUTTON (COM-CLOSE)
When the gate is standstill, it operates the closing.
JOGGING OPERATION BUTTON (COM-K BUTTON)
DIP5 - OFF => It cyclically commands open-stop-close-stop-open-etc.
DIP5 - ON => It opens the gate when this Is closed. If It is operated while the gate is
opening, it has no effect. If it is operated when the gate is open, it closes the
gate and, if it is operated while the gate is closing, it opens the gate again.
DIP4 - OFF => It cyclically commands open-stop-close-stop-open-etc.
DIP4 - ON => It opens the gate when this is closed. If it is operated while the gate is
opening, it has no effect. If it is operated when the gate is open, it closes. If
it is operated while the gate is closing, it opens the gate again.
Pause times before the automatic closing of the gate are set with the timing procedure.
The maximum pause time is 5 minutes.
Pause time can be started or stopped by DIP3 (ON started).
RADIO TRANSMITTER
AUTOMATIC CLOSING
ELECTRIC LOCK IN OPENING PHASE
Set Dip10 to ON to enable control of the electric lock in the opening phase.
ELECTRIC LOCK AND RELEASE PULSE IN OPENING PHASE
Set Dip11 to ON to enable the release pulse of the electric lock in the opening phase (provided
S2 Dip10 is set to ON).
With the gate closed, pressing an opening command will cause the gate to perform the closing
movement for 0.5s (in this phase the Encoder(s) is/are not enabled), and simultaneously the
electric lock is activated (followed by 0.5s pause and then by opening of the gate).
GATE LEAF RELEASE ASSIST
With the electric lock release pulse active (Dip11 - ON), when the gate is closed a direction
reversal manoeuvre is performed for a fixed time of 0.2s to facilitate manual release (in this
phase the Encoder is not enabled).
OPERATION AFTER BLACK-OUT
When mains electrical power is restored press the opening button (K, OPEN, radio).
Let the gate close itself with automatic closure or wait that the flasher
The gate will open.
stops blink first to command the closing movement. This operation is valid to obtain the
leaves position readjustment.
During this phase all safety devices are active.
SAFETY ACCESSORIES OPERATION
PHOTOCELL 1 (COM-PHOT 1)
If DIP 6 is OFF - The gate does not open if there is an obstacle within the photocells
range of action.
During operation, photocells work both when the gate opens (by starting the opening
movement again after half a second time), and when it closes (by starting the reverse
movement after one second time).
If DIP 6 is ON - If there is an obstacle within the photocells range of action when the gate
is closed and its opening is commanded, the gate opens (during Its
opening, photocells do not work).
Photocells work only while the gate Is closing (by starting Its reverse motion after one
second, even if they are still engaged).
N.B.: Every six months make sure to check that photocells are not out of order
(EN12453)
STOP BUTTON
The STOP button stops the gate during any operation.
If you push it when the gate is totally open (or partly open, by using the pedestrian
command), this button temporary excludes the automatic closing (if selected by DIP3). It
Is than necessary to operate another command to make the gate close again.
The automatic closing function Is enabled again with the following operating cycle (if
selected by DIP3).
N.B.: This electric board can supply power ONLY TO BLINKERS WITH BLINKING
CIRCUIT (ACG7059), with max. 40W lamps.
PRE-BLINKING FUNCTION:
DIP 8 - OFF => the motor, the blinker and the buzzer start at the same time.
DIP 8 - ON => the blinker and the buzzer start 3 seconds before the motor.
BUZZER (Optional)
Wiring acoustic warning (12Vdc max 200 mA).
The buzzer emits an intermittent sound signal during opening and closing cycles.
When safety devices are operated (alarm), the intermittence frequency of this sound
signal Increases.
WARNING LIGHT - GATE OPEN (COM-SIGNAL):
Its function Is to signal when the gate Is open, partly open or not totally closed anyway. It
turns off only when the gate is totally closed.
This warning signal is not enabled during the programming procedures.
N.B.: If you overuse the push button panels or the lamps, the control board logic
system may be compromised, resulting into a possible operation block.
the external copper sheath, since this would prevent the antenna from working.
Install the antenna vertically and in such a way the remote control can reach it.
SPARK ANTENNA 91 code ACG5454
SPARK ANTENNA 433 code ACG5252
BLINKER
