CoolAir RT780
7.6

Installing the electrical supply lines

!
WARNING!
• The electrical power supply may only be performed by qualified personnel
with specialist knowledge.
• Make sure there is no voltage present on electrically operated components
before carrying out work on them!
A
NOTICE!
• Fit a fuse of 25 amps to the connection to the vehicle's power supply.
• The battery must be able to supply the required current and voltage
(chapter "Technical data" on page 25).
I
NOTE
The unit is equipped as standard with a 4 m long cable with a cross-section of
2
6 mm . If longer cable lengths are required, then the cable cross-section must
be increased by an authorised specialist workshop:
In this case cut off the cable as closely as possible to the unit (max. 0.5 m) and
then establish a suitable connection with a larger cable cross-section.
When the cable is extended by 4 m to 6 m in length, the manufacturer
recommends using a cross-section of at least 8 mm
You can connect the unit to the battery via the lorry's terminal block or directly.
The terminal block is to be preferred for the connection. Ask your vehicle
manufacturer for the specifications of the terminal block.
➤ Lay the supply line and connect it to the vehicle (red line to plus, black line to
minus).
➤ Plug in the supply line plug into the socket of the air conditioning roof unit
supply line.
➤ To relieve strain on the supply line, secure it with a cable tie, e.g. to the cab
roof.
7.7

Preparing the cover frame

A
NOTICE!
Screw the screws in carefully order not to damage the cover frame.
➤ Unless you have a Renault Trucks specific cover, place the cap (fig. 7 2,
page 6) included in the supply in the cover frame.
➤ Fasten the cap (fig. 7 2, page 6) with the four cylindrical screws M4 x 12
(fig. 7 1, page 6), washers M4 (fig. 7 3, page 6) and the self-locking nuts
M4 (fig. 7 4, page 6).
EN
Installation
