The rating plate is on the bottom of the
hob.
Serial number ...........................
Built-in hobs
Only use the built-in hobs after you
assemble the hob into correct built-in units
and work surfaces that align to the
standards.
Assembly
min.
500mm

TECHNICAL DATA

Rating plate
Model PAS8065E
Typ 60 HBD 47 AO

Connection cable

• The hob is supplied with a connection
• To replace the damaged mains cable,
min.
50mm
min.
28 mm
PNC 949 594 324 01
220 - 240 V 50 - 60 Hz
Made in Germany
cable.
use the cable type: H05V2V2-F which
withstands a temperature of 90°C or
higher. Speak to your local Service
Centre.
R 5mm
mm 750
+1
490
min.
55mm
min.
20 mm
Progress 13
+1
mm
min.
12 mm
