5

Product information

5.1

Type key

5.2

Technical data

Property
Speed range
Nominal diameters DN
Pipe connections
Permissible min./max. fluid temperature
Ambient temperature min./max.
Storage temperature min./max.
Maximum permitted operating pressure
Insulation class
Protection class
Electromagnetic compatibility
Emitted interference in acc. with
Interference resistance in acc. with
Sound-pressure level
2)
Permissible fluids
Electrical connection
Internal electric circuit
Speed control
Installation and operating instructions Wilo-CronoLine-IL-E, CronoTwin-DL-E, CronoBloc-BL-E
Value
750 – 2900 rpm
380 – 1450 min
IL-E/DL-E:
40/50/65/80/100/125/150/200 mm
BL-E:
32/40/50/65/80/100/125 mm (pressure
side)
Flanges PN 16
-20 °C to +140 °C
0 to +40 °C
-20 °C to +60 °C
16 bar
F
IP 55
EN 61800-3
EN 61800-3
1)
L
Heating water according to VDI 2035
Cooling/cold water
Water/glycol mixture up to 40% vol.
Heat transfer oil
Other fluids
3~380 V -5%/+10%, 50/60 Hz
3~400 V ±10%, 50/60 Hz
3~440 V ±10%, 50/60 Hz
PELV, galvanically isolated
Built-in frequency converter
The type key consists of the following elements:
Example: IL-E 80/130-5.5/2-xx
DL-E 80/130-5.5/2-xx
BL-E 65/130-5.5/2-xx
IL Flange-end pump as In-line single pump
DL Flange-end pump as in-line Double pump
BL Flange-end pump as MonoBloc pump
-E with Electronic module for electronic speed control
80 Nominal diameter DN of the flange connection
(for BL-E: pressure side) [mm]
Impeller diameter [mm]
130
5.5 Rated power P
2 Number of poles, motor
xx Variant: e.g. R1 – without differential pressure
sensor
-1
< 83 dB(A) | ref. 20 μPa
pA, 1m
[kW]
2
Remarks
Depending on pump type
EN 1092-2
Depending on fluid
Lower or higher ambient
temperatures on request
Residential
Industrial
Depending on pump type
Standard version
Standard version
Standard version
Only for special version
Only for special version
Supported mains types:
TN, TT
English
69
