GB ENGLISH
Important:
Before starting fitting work,
make sure there will still be
sufficient air flow to the
radiator grille (engine
cooling). Attach both head-
lamps above the bumper.
Fitting measurements:
Rallye 3000 Compact, 3000 Compact Celis, 3003 Compact
In Germany, all
the additional fitting
measurements shown
in the sketches below
must be observed when
fitting auxiliary driving
lamps with an integrated
position light. If these
mandatory fitting
requirements are not
1.500
mm
350mm
max.
min.
600mm
min.
observed or the use of
an additional pair of
position lights is not
permitted (e.g. in CH, A),
the position light must not
be operated. In this case,
the cables to the position
lights have to be
disconnected. There are
no special regulations for
max.
4 m
400mm
max.
the attachment of auxiliary
driving lamps.
The maximum attachment
height of 4 m must not be
exceeded. The legal
regulations in individual
countries must be taken
into account.
