DC supply:
10 ... 30 V DC/ max. 4.5 W
reverse polarity protection
SELV, CLASS II (Limited
Power Source)
ext. fuse protection T 0.2 A
10.8
Sensor supply voltage
(Voltage output for external sensors)
SELV circuits, reinforced / double insulation
for AC supply:
24 V DC ±15%, 80 mA
for DC supply:
max. 80 mA, external voltage
supply is connected through
10.9
Climatic Conditions
Operating temperature: -20°C .. +65°C
Storage temperature:
Relative humidity: RH. 93% at +40°C,
Altitude:
10.10 EMC
Noise immunity:
EN 61000-6-2
with shielded signal and
control cables
Noise emission:
EN 55011 Class B
10.11 Device safety
Design to:
EN 61010 Part 1
Protection Class:
Protection Class 2 (front side)
Only the front side is classified as accessible
for the operator.
Application area:
Insulation:
Signal inputs and und sensor power supply: SELV
10.12 Mechanical Data
Housing:
Panel-mount housing
to DIN 43 700, RAL 7021
Dimensions:
48 x 48 x 91 mm
Panel cut-out:
45
Installation depth:
ca. 107 mm incl. terminals
Weight:
ca. 125 g
Protection:
IP65 (front, device only)
Housing material:
Polycarbonate UL94 V-2
Vibration resistance: 10 - 55 Hz / 1 mm / XYZ
(EN60068-2-6):
30 min in each direction
Shock resistance
100G / XYZ
(EN60068-2-27):
3 times in each direction
(EN60068-2-29):
10G/6 ms/XYZ 2000 times in
each direction
www.kuebler.com
-25°C .. +75°C
non-condensing
to 2000 m
Pollution level 2
over-voltage Category II
Front: double insulation,
Rear side: basic insulation,
+0,6
+0,6
x 45
mm
10.13 Connections
Supply voltage and output:
Plug-in screw terminal, 7-pin, RM5.08
Core cross section, max. 2.5 mm²
Signal and control inputs:
Plug-in screw terminal, 8-pin, RM 3.81
Core cross-section, max. 1.5 mm²
11 Scope of Delivery
Delivery includes:
Preset counter
Mounting clip
Instruction manual
12 Ordering codes
6.923.X10X.XX0
Input trigger levels
Supply voltage
LCD version
Output
Front
• 24 VAC power supply on request
0 = Standardlevel (HTL)
A = level 4-30 VDC*
0 = 100...240 V AC ± 10%
2 = 24 VAC +/- 10%
3 = 10 .. 30 VDC
0 = no backlighting
1 = green backlighting*
2 = LED Look*
3 = Multicolour
0 = Relay
0 = Kübler version
A = Neutral version*
