3.3 ELECTRICAL WIRING

WARNING
DO NOT EXCHANGE NEUTRAL WITH PHASE
~
50Hz 230V
PE L N
Safety
thermostat
7 pin plug
7 pole socket
D1823
Ignition
electrodes
B
2899
WARNING
Main switch
T6A
Limit
thermostat
Heater
Black
White
Blue
Burner-earth
Flame detector
Fig. 13
For burners installed on air
g e n e r a t o r s , r e m o v e t h e
bridge (B, fig. 13) from the
control box.
E9114
NOTES:
– Wires of min. 1 mm
(Unless requested otherwise by local standards
and legislation).
– The electrical wiring carried out by the installer
must be in compliance with the rules in force in
the Country.
TESTING
Check the shut-down of the burner by
opening the thermostats.
Hour counter
(230V - 0.1A max.)
CONTROL BOX
To remove the control-box from the
burner, loosen screw (A, fig. 11) and
pull to the arrow direction, after re-
Remote
lock-out signal
moving all components, the 7 pin plug
(230V - 0.5A max.)
and earth wire.
Start thermostat
Motor
Capacitor
Oil valve
ACCESS TO THE FLAME DETECTOR
(see fig. 12)
The flame detector is fitted directly into
the control-box (underneath the ignition-
transformer) on a plug-in support.
Ignition
transformer
Flame detector
5 GB
2
section.
Fig. 11
E9116
A
Fig. 12
E9141
