b) Connecting the Aerial
• Connect the aerial plug of your vehicle with the aerial socket ANT at the back of the radio.
• If your vehicle has a different aerial plug, please use a suitable adapter, available in specialist shops.
c) Connecting the LINE Outputs
The CD tuner has a LINE output for connecting a power amplifier.
For the connection of the cinch sockets only use the shielded cinch wires. The use of other
cables might cause interferences.
Keep the distance of the cables as short as possible.
Do not place the cables near other cables to avoid interferences in the cables.
To avoid distortions or mismatchings that could damage the unit, the cinch connector must only
be connected to devices with the suitable cinch terminals. For this, observe also the connection
data in the section "Technical Data".
• Connect the sockets LINE OUT on the back of the device with the inputs of a power amplifier.
The red socket is a terminal for the right channel
The white socket is a terminal for the left channel
d) AUX IN Connection
You can connect an external audio device (e.g. portable MP3 player) to the port AUX IN (14) whose signal
is played back via the vehicle speakers.
• Connect the port AUX IN (14) with the audio output of the external device.
