INSTRUCTIONS FOR USE AND MAINTENANCE
4.6.7 Automatic vacuuming & charging completed
Once the charge has been completed, the message
"vacuuming & charging completed" will appear, and the
green LED will cease to flash.
Pressing any key will cause the system to go into scales
mode.
4.7. Gas recovery function
Before selecting the gas recovery option, tare the scales.
Connect the recovery unit to the plug (fig 13).
Plug in the recovery unit.
Place the bottle on the scales.
Disconnect the vacuum pump (fig 12).
Select the gas recovery option on the menu.
Select the amount to be controlled.
Confirm.
4.8. Reset
Once the automatic reset working option has been
confirmed (see 2.2)
4.8.1 Resetting the parameters.
Clearing the tare of the scales.
Programmed charge set to minimum.
Time to create vacuum programmed equal to default
value.
4.8.2 Reset completed.
Message "reset" and green LED lit without flashing.
Pressing any key will cause the system to go into scales
mode.
5. Ordinary Maintenance
Ordinary Maintenance
5.1 Replacing the vacuum pump oil.
The oil must be replaced at least after every 20 hours
of use and at least once every six months, even if the
equipment has not seen continuous use.
Replacing the oil is also essential if it has any residues or
is cloudy in appearance; Contaminated oil, apart from
preventing the pump from achieving acceptable vacuum
levels, can cause irreparable damage to the mechanical
parts of the pump itself.
All the tasks relating to the removal and replacement of the
oil are carried out with the vacuum pump switched off.
- Before removing the oil, leave the pump running for at
least 10 minutes.
- Turn the equipment off by setting the switch no. 3
to position 0 and removing the cable from the power
supply, strictly in that order.
- Remove the drainage plug from the pump situated on
the lower part of the pump.
- Allow all the oil to drain completely
- Replace the drainage plug of the pump tightly
- Remove the filler cap no. 6 located on the upper part
of the pump
- Fill slowly with oil until the level reaches the halfway
position on the visor located at the rear of the pump.
- Replace filler cap no. 6.
WARNING
!
The lubricant must not be disposed of into the
environment; it is a special residue and, as such, it
must be disposed of in compliance with the legislation
in force.

6. Removal / Recycling

Some parts of the appliance are recyclable. There are
centres which are recognised and certified for the collection
of these recyclable materials. For environmentally friendly
disposal of non/recyclable parts (eg. scrap from the
electronic system), please contact your local waste disposal
department.
