Assembly

Firebox 1x
Grate Holder
Leg Bracket
Screw M6x12
Washer Ø6
Nut M6
brackets on the outside by use of
The center holes of the grate hold-
ers must remain free.
Ash Tray Bracket
Screw M5x12
Washer Ø5
Wing Nut M5
Attach the ash tray bracket to the
The ash tray bracket mountings
are positioned unsymmetrically, so
that it can only be attached in one
position.
1
6x
M6x12
3x
3x
6x
6x
6xØ6
6x
6xM6
2
1x
3xM5
3x
3x
3x
3xØ5
3x
M5x12
Remove the
washer pic into
the fire bowl.
ENGLISH | 123
