EN | Operating instructions
Accessories, loose
Order No.
HZD80/420RG
HZDE80/420RG
EV05/640
MK/630-G08-G08
TRAP2/100-G230/P
TRAP2/100-G115/P
TRAP2/100-G24D/P
TRAP2/350-G230/J
TRAP2/350-G115/J
TRAP2/350-G24D/J

Spare and wear parts

Order No.*
1050_
1070_
1140_
2010_
2020_
2030_
2050_
RKGH3-GH7
RKGH9-GH13
KT1012_
KT1019_
KT2016_
* Replace the underline by element degree / filling
Parts overview (for overview drawing on page 27)
Pos.
1 Differential pressure gauge (incl. seal and screwed connection)
2
3
4
5
6
7
8
9
10
8
Description
calibrated analogue differential pressure gauge
calibrated analogue differential pressure gauge with Reed contact
Manual drain (needle valve) PN640, G1/4i
Assembly kit G1/4a, PN630, for drain G1/4i
Time controlled solenoid valve G1/4i, PN100, 2-55 °C, 230 VAC, IP65
Time controlled solenoid valve G1/4i, PN100, 2-55 °C, 115 VAC, IP65
Time controlled solenoid valve G1/4i, PN100, 2-55 °C, 24 VDC, IP65
Time controlled solenoid valve G1/4i, PN350, 2-55 °C, 230 VAC, IP65
Time controlled solenoid valve G1/4i, PN350, 2-55 °C, 115 VAC, IP65
Time controlled solenoid valve G1/4i, PN350, 2-55 °C, 24 VDC, IP65
Description
8 O-rings for filter housing GH3-GH7 (2 x required for each housing)
8 O-rings for filter housing GH9-GH13 (2 x required for each housing)
Cartridge for filter size GH3 and GH5
Designation
Plug screw
Protective caps of the retaining bores
Filter top section
Threaded rod
Filter element with element seal
Housing O-rings
Filter bottom section
Assembly kit
Manual drain valve
High-pressure filter for compressed air
Filter element for filter size GH3
Filter element for filter size GH5
Filter element for filter size GH7
Filter element for filter size GH9
Filter element for filter size GH11
Filter element for filter size GH12
Filter element for filter size GH13
Cartridge for filter size GH7
Cartridge for filter size GH9
Accessories
Consumable
Consumable
Accessories
Accessories
GH3-GH13_Rev.03
