Safety Instructions For Maintenance; Operation - Husqvarna Duratiq 6 Propane Manuel D'utilisation

To do a check of the emergency stop button on the
control panel
1. Turn the emergency stop button on the control panel
clockwise to make sure that the emergency stop
button is disengaged.
2. Start the engine. Refer to
control panel on page 18 .
3. Push the emergency stop button.
Introduction
WARNING: Before you operate the product,
you must read and understand the safety
chapter.
To remove the product from the
package
WARNING: Move the product from the pallet
carefully and safely. The product is heavy
and can cause serious injury if it falls.
• Make sure that all items that is shown in the product
overview, are included. Refer to
right side on page 3 . Speak to your Husqvarna
dealer if an item is missing or damaged before you
move the product from the pallet.
• Remove all package straps and wheel chocks.
• Make sure that the area is clear and that you have
sufficient space to move the product.
• Make sure that there is no risk that you or the
product can fall.
• Use lifting equipment or ramps to move the product
from the pallet. The product is heavy. Move the
product safely. Refer to
33 .
To do before you operate the product
1. Read the operator's manual carefully and make sure
that you understand the instructions.
2. Put on necessary personal protective equipment.
Personal protective equipment on page 10 .
Refer to
12
To start the product with

Operation

Product overview,
To lift the product on page
4. Turn the emergency stop button clockwise to
disengage.

Safety instructions for maintenance

• Keep all parts in good condition and make sure that
all fixtures are correctly tightened.
• Do not use a product that is defective. Do the safety
checks, maintenance and the servicing as given in
this manual. All other maintenance work must be
done by an approved service agent.
• Installation and repair of the supply system for
propane must be done only by approved servicing
personnel for propane systems.
• Stop the product when you replace the diamond
tools. Push the ON/OFF button on the control panel
and push the emergency stop button.
• Do the inspection and/or maintenance with the
engine stopped.
• Do the maintenance to make sure that the product
operates correctly. Refer to
on page 23 .
3. Make sure that only approved persons are in the
work area.
4. Do daily maintenance. Refer to
schedule on page 23 .
5. Make sure that the product is assembled correctly
and is not damaged.
6. Put the product on the work area. Make sure that the
transportation of the product to and in the work area
is done safely and correctly. Refer to
safety on page 10 .
7. Make sure that there are diamond tools on the tool
plates and that the diamond tools and tool plates are
tightly attached.
8. Connect a dust extractor to the product. Refer to
connect a dust extractor on page 14 .
9. Adjust the handle and the handlebar to an applicable
operation height. Refer to
the handlebar on page 15 .
10. Make sure that the battery is connected. Refer to
connect the battery on page 17 .
11. Make sure that the propane tank is connected. Refer
To connect and disconnect the propane tank on
to
page 17 .
12. Fill the tank with cold water. Refer to
tank with water on page 25 .
13. For wet grinding, connect a water hose to the
To connect the product to a water
product. Refer to
hose on page 17 .
Maintenance schedule
Maintenance
Work area
To
To adjust the handle and
To
To fill the water
