Operating Instructions

Basic Operations

Follow the instructions below to operate and program the RSX LED fixture.
English
The RSX turns on automatically when power is connected, and turns off when
power is cut.
When power is resumed, the RSX will restore to the previous saved setting automatically,
whether it was last set at Manual or Automatic Mode, and the intensity level of all the LED
channels.
The fan on the RSX fixture is temperature controlled.
The RSX has a built-in temperature control system. The fan will be automatically engaged
when the temperature is above 55° C/131° F, and disengage when it is below 45°C/113°F.
Below 45° C/113° F Above 55° C/131° F Above 65° C/149° F
If the fan fails, the system may overheat and the system will enter fail-safe mode when the
temperature is above 80° C/176° F, turning off all channels. The system will exit fail-safe mode
and resume normal operation when the temperature drops below 70° C/158° F.
Switching between Auto and Manual Mode
The RSX has two modes of operations: Auto and Manual Mode. User can switch between the
two modes with the control dial on the fixture.
3s
 Press and hold the control dial for 3 seconds to switch to
another mode.
6
