NOTIFICATION SIGNS - TECHNICAL DATA
PROBLEMS
• If the dip-switch is set wrong the following message appears.
• If the instrument fails to recognise the attached battery charger the following window appears.
Check that the battery charger is from the SBC ADV PLUS series.

TECHNICAL DATA

MODEL
INPUT CHARACTERISTICS
Supply voltage (1)
Maximum absorption
(2)
AMBIENT CHARACTERISTICS
Operating temperature
(3)
GENERAL
Dimensions (W x H x D)
Weight
Communication interface
EMC class
The instrument can reset itself at a voltage less than 8 Vdc.
(1)
Typical value with backlighting on at high intensity.
(2)
At temperatures below 0°C the movement of the display crystals slows down.
(3)
®
QUICK RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
RDS 1540 - REV003A
RDS 1540
from 8 to 30 Vdc
120 mA
from -20 to + 70° C
120 mm x 65 mm x 34 mm
140 g
CAN BUS with differential transceiver
EN 61326-1 - EN 55011-B - FCC part 15 rules 47
GB
19
