OPERATING
GB
SETTING UP THE INSTRUMENT
The instrument is set up using a dip-switch. To configure the unit, priority of the battery charger which the infor-
mation is shown for and CAN termination, refer to the table given below:
SWITCH 1 SWITCH 2
OFF OFF
OFF ON
ON OFF
SWITCH 3 SWITCH 4
OFF OFF
OFF ON
ON OFF
SWITCH 5 FUNCTION
CAN TERMINATOR DEACTIVATED
OFF
CAN TERMINATOR ACTIVATED
ON
SWITCH 6 FUNCTION
Backlighting intensity LOW
OFF
ON
Backlighting intensity HIGH
SWITCH 7 SWITCH 8
OFF OFF
OFF ON
ON OFF
ON ON
16
FUNCTION
A
GROUP
B
GROUP
C
GROUP
FUNCTION
1
PRIORITY
2
PRIORITY
3
PRIORITY
FUNCTION
Voltage display MASTER
Voltage display MASTER, SLAVE A
Voltage display MASTER, SLAVE B
Voltage display MASTER, SLAVE A / B
DESCRIPTION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
DESCRIPTION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
DESCRIPTION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
DESCRIPTION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
DESCRIPTION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
RDS 1540 - REV003A
