FACTORY SETTING:

A possible CAN network is illustrated below:
GROUP A
UNITS IN PARALLEL
SBC 1950
SBC 1950
ADVANCED
ADVANCED
PLUS
PLUS
(Priority 1)
(Priority 2)
RDS 1540
KTB4
For more information about battery charger configuration, consult the User's manual for the battery charger
used.
INSTRUMENT OPERATION
Before attempting to turn on the instrument, make certain the dip - switch is set to the correct position. After
hooking up the instrument to the power supply, the display shows the following window for 2 seconds.
When X.YY is the current version of the software.
After 2 seconds the instrument displays the battery charge information.
Example with SBC 700 ADV PLUS.
RDS 1540 - REV003A
:
Group
A
:
Priority
1
CAN Termination
Backlighting intensity
Voltage display
SBC 1950
ADVANCED
PLUS
(Priority 3)
CAN NETWORK
RCM1620
RDS1520
MASTER OUT
SLAVE A OUT
CURRENT
:
DEACTIVATED
:
LOW
:
MASTER
GROUP B
SBC 1100
ADVANCED
PLUS
(Priority 1)
RCM1620
RDS1540
SLAVE B OUT
STATUS
OPERATING
GROUP U
GSM
RDS1520
INTERFACE
GB
LCD
TERMINAL
17
