CHARACTERISTICS AND INSTALLATION
GB
RDS 1540
The RDS 1540 remote display allows status of the SBC ADV PLUS medium and high power battery chargers to be
monitored through the CAN BUS interface.
Other important advantages which the RDS 1540 offer, are:
• Alphanumeric LCD display.
• Option of choosing whether to display one, two, or all three output voltages from the battery charger.
• Display of the total current supplied by the battery charger.
• Backlight display screen with 2 brightness levels.
• Automatic display contrast compensation according to environmental temperature.
• Universal power supply (12/24Vdc).
• CAN BUS interface for data transfer.
• Easy installation.
• Can work in a wide range of ambient temperatures.
INSTALLATION
BEFORE USING THE INSTRUMENT CAREFULLY READ THIS USER'S MANUAL. IN CASE OF DOUBT
CONTACT THE "QUICK
F
In case of discordance or errors in translation between the translated version and the original text in the
Italian language, reference will be made to the Italian or English text.
F
This device was designed and constructed for use on recreational crafts.
Other forms of use are not permitted without written authorization from the company Quick
®
The Quick RDS 1540 remote display has been designed for the purposes and tasks outlined in this User's
®
Manual. Quick shall not be held responsible for any direct or indirect property damage or personal injury
caused by inappropriate or unintended use of the equipment, erroneous installation or any errors that may be
present in this manual.
THE WARRANTY SHALL BE VOID IF THE INSTRUMENT IS TAMPERED WITH OR ALTERED BY NON
AUTHORISED PERSONNEL.
THE PACKAGE CONTAINS: RDS 1540 - drilling template - connecting cable - user's manual - conditions of warranty.

INSTALLING THE INSTRUMENT

The typical installation procedure is described herein. Needless to say, it is not possible to describe a procedure
applicable for all situations that may be encountered.
Adapt this procedure to satisfy your own personal requirements.
Locate the most suitable position to house the instrument following the recommendations given below:
• The instrument should be installed in a place where it can be easily read by the operator.
• Select a clean, smooth and flat area.
• Access from the rear must be available for installation and maintenance purposes.
• Leave enough space free behind the installation to conveniently fit the back of the instrument and the
connectors.
• The back of the instrument must be protected against contact with water and moisture.
• Pay careful attention when drilling the panel or parts of the boat. This hole should not weaken or
break/crack the boat's structure.
12
®
" SUPPLIER OR AFTER SALES SERVICE DEPARTMENT.
®
.
RDS 1540 - REV003A
