GRAPHIC SWITCHER II™
Chapter 3 : TECHNICAL DESCRIPTION
3-1. FRONT PANEL
INPUT SELECT (PROGRAM & PREVIEW)
1 to 8 :
9 to 16 :
S1 to S4 :
SDI :
BLACK :
TRANSITION - EFFECTS
TAKE :
1, 2, 3, 4 :
FREEZE MAIN
FREEZE PREVIEW
ADJUST
RECALL / STORE : STORE (a long push, LED = ON):
POS / SIZE :
H :
V :
MAIN & PREVIEW : Output selection for the adjust functions.
NOTE: The adjust functions are active on the output indicated by the turned ON LED's (MAIN and/or PREVIEW).
LCD WINDOWS
CONTROL
EXIT / MENU :
ENTER :
STEP
(SEQUENCE)
8 RGB/YUV input selection keys.
8 Composite Video input selection keys.
4 S.VIDEO (Y/C) input selection keys.
Optional SDI input selection key.
BLACK screen selection key.
Allows to switch the pre-selected input (blinking key) on the MAIN output with the pre-
selected EFFECT (EFFECT KEYS).
Four EFFECT keys. Each of those keys can store one of the effects available in the LCD effect
menu.
Allows to FREEZE the MAIN output image (active when the key is ON).
Allows to FREEZE the PREVIEW output image (active when the key is ON).
RECALL (a short push on the button): allows to recall the stored image settings for the
NOTE: The GRAPHIC SWITCHER II
Position or Size mode selection. (Acts on H & V buttons).
Horizontal image control (position or size).
Vertical image control (position or size).
Allows to select items in the LCD menu.
Allows to exit from a LCD menu.
Allows to validate the selected item.
Allows to directly step through a programmed switching sequence.
allows to store for each input, the image adjustments
(position, size).
selected input.
™
has 40 NON-volatile image setting memories.
PAGE 7
