Parts list
No.
Description
81
Lock washer (ø8)
82
Nut M10
83
Nut M8
84
Nut M10
85
Nut M8
86
Nut M6
87
Nut M3
88
Bungee cord
89
Nylon strap
90
Plate
91
Pedal cap
92
Bolt (M4x12)
93
Nut M5
94
Chest belt (optional)
95
Strap

Assembly instructions

Step 1
Slide the seat (31) onto the sliding rail (3) and attach the rear end cap (97) with two bolts M5x10 (98).
Step 2
Attach the stoppers (13) to the sliding rail (3) with two bolts M6x20 (71) and washers ø6 (79).
Step 3
Fix the rear support (4) on sliding rail (3) with 4 bolts M8x15 (69) and 4 washers ø8 (78).
24
Qty
No.
1
96
Plastic washer (ø20)
2
97
Rear end cap
1
98
Bolt (M5x10)
3
99
Left front cover
7
100
Right front cover
2
101
Screw (M5x12)
12
102
Wrench
1
103
Allen wrench (5 mm)
2
104
Allen wrench (6 mm)
1
105
Combination wrench
2
106
Caution label
2
107
Syphon pump
8
108
Funnel
1
109
Console cover
1
110
Rubber ring
Description
Qty
1
1
2
1
1
4
1
1
1
1
1
1
1
1
1
