21. TECHNICAL DATA

Operating voltage ....................................11 - 18 V/DC
Power input ..............................................Depending on the charging current and rechargeable battery, max. approx.
Charging/discharging channels ...............4
Charge current .........................................0.1 - 6.0 A (per channel)
Max. charging output ...............................80 W (per channel)
Discharge current ....................................0.1 - 2.0 A (per channel)
Max. discharging output ..........................10 W (per channel)
Suitable rechargeable batteries ...............NiMH/NiCd, 1 - 15 cells
Discharging current for balancer .............200 mA per cell
Ambient conditions ..................................Temperature 0 °C to +40 °C, humidity 0% to 80% relative, non-condensing
Weight .....................................................1130 g
Dimensions ..............................................225 x 160 x 62 mm (W x D x H)
33 A at 12 V/DC
(we recommend either a mains unit with an output performance of at least
400 W or a suitable 12 V car lead battery)
LiPo/LiIon/LiFe, 1 - 6 cells
Pb, 1 - 10 cells (rated voltage 2 - 20 V)
85
