Aspect Ratio
PASSWORD
RATING
DEFAULT
OSD Language
Audio
Subtitle
DVD Menu
hDMI cEc

hDMI AUDIO

46
To avoid distortion on older televisions, you may need to change the
way in which the image is displayed. Televisions use a 4:3 aspect ratio;
high-definition televisions use 16:9 aspect ratio (as do movies).
• Some discs do not allow the aspect ratio to be changed and you will
therefore have to change the aspect ratio on the TV.
[4:3PS]: This mode is used with 4:3 televisions. 4:3 images are displayed
normally. When showing 16:9 programmes, the full height of the
screen is displayed, and the left and right part of the image are cut
off.
[4:3LB]: This mode is used with 4:3 televisions. 4:3 images are displayed
normally. 16:9 images are visible at their full width, but there are
blank area at the top and bottom of the screen.
[16:9]: Use with a 16:9 wide television.
• Some wide-screen discs that do not permit the Pan Scan mode
playback are automatically played in Letter Box mode.
• Depending on the DVD, 4:3 Letter Box may be selected
automatically instead of 4:3 Pan Scan and vice versa.
• If 16:9 (Wide) is selected and a normal TV is connected, 16:9
content will appear distorted during playback (objects look thin).
you can set a new password for parental control.
Playback of some DVD discs can be limited depending on the age of the
users. The parental control system allows the playback limitation level to
be set by the parent.
• The lower the level, the stricter the limitation.
• If the rating of the loaded DVD disc is higher than the level you set,
the system will require a password. Enter your password and press
the ENTER button to start playback.
All the items in the Setup menu (except for the password and parental
control) will be reset to the default settings.
Select the desired language for on screen menus of the unit.
you can select a preferred language for audio, subtitle and disc menu.
• When you select a preferred language that is not recorded on the
DVD, one of the recorded languages is automatically selected.
• you can override the Audio setting in the Setup menu by pressing the
AUDIO button on the remote control unit while a DVD disc is playing.
• you can override the Subtitle setting in the Setup menu by pressing the
SUBTITLE button on the remote control while a DVD disc is playing.
you can use one single remote control to control all hDMI cEc devices
that connected via hDMIconnection.
ON: Enable hDMI-cEc feature. OFF: Disable hDMI-cEc feature.
AUTO: Detect and select the best supported audio format automatically.
PcM: Multi-channel audio format will be down-mixed to two channel
sound.
