Quickie R-Net Manuel D'utilisation page 26

Fig.7.6
Set Time
Display Time
Distance
Backlight
Background
Exit
Fig.7.7
Total Distance
Trip Distance
Display Distance
Clear Trip Distance
Exit
Fig.7.8
Set Time
Display Time
Distance
Backlight
Background
Exit
26
>
<12hr>
>
<Blue>
<Blue>
>
012345
0012.3
<Trip>
>
>
>
>
>
<100%>
<Blue>
>
7.4 Distance
This sets the functionality of the odometer. To select the
distance option:
• Deflect the joystick backwards until "Distance" is highlighted,
(Fig 7.6).
• Deflect the joystick to the right to select the option.
• The next screen appears, (Fig 7.7).
Total Distance.
This is a value held in the Power Module and relates to the total
distance driven using that Power Module.
Trip Distance
This is a value held in the joystick module and relates to the
total distance driven since the last reset.
Display Distance
Sets whether Total Distance or Trip Distance appears as the
odometer display on the LCD Screen.
• Move the joystick backwards until "Display Distance" is
highlighted.
• Deflect the joystick to the right to select "Total" or "Trip".
• Move the joystick backwards or forwards to exit "Display
Distance".
Clear Trip Distance
To clear the Trip Distance value:
• Deflect the joystick backwards until "Clear Trip Distance" is
highlighted.
• Move the joystick to the right to clear the displayed value.
• Deflect the joystick backwards or forwards to exit the "Clear
Trip Distance".
Exit
Move the joystick backwards until "Exit" is highlighted.
A right joystick deflection will retune to the Settings Menu,
(Fig 7.8).
R-Net Control System | Rev. H | English
