Removing the attachment tool
1. Open drill chuck: Turn the keyless
chuck (2) ⭮ .
CAUTION! Risk of burn injury!
2.
Attachment tools – especially drills –
can become very hot. Wear protective
gloves whenever appropriate.
Remove the attachment tool.
Adjusting the auxiliary
handle
Notes
• The auxiliary handle (19) can be ro-
tated 360 ° on the device and can be
moved to any desired position.
• Directional data viewed from behind.
Attaching the auxiliary handle
(Fig. C)
1. Turn the grip (23) of the auxiliary
handle (19) ⭯ .
2. Press the grip (23) towards the loop
(18) and hold this position. This ex-
tends the loop (18).
3. This extends the loop (18) of the aux-
iliary handle (19) behind the keyless
chuck. (2). Position the loop (18) in the
holder for the auxiliary handle (4).
4. Release the pressed grip (23).
5. Tighten the grip (23) of the auxiliary
handle (19) ⭮ .
Removing the auxiliary handle
(Fig. C)
1. Turn the grip (23) of the auxiliary
handle (19) ⭯ .
2. Press the grip (23) towards the loop
(18) and hold this position. This ex-
tends the loop (18).
3. Remove the auxiliary handle (19) from
the device by pulling the loop (18) on
the auxiliary handle (19) over the key-
less chuck (2).
Setting the depth stop
(Fig. C)
1. Release ⭯ the locking screw (24) for
the depth stop (20).
2. Push the depth stop (20) into the small
opening on the auxiliary handle (19).
3. Position the depth stop (20) so that the
distance between the tip of the drill
and the tip of the depth stop corres-
ponds to the desired drilling depth.
4. Fix the depth stop (20) by tightening
the locking screw (24) ⭮ .
5. Loosen ⭯ the locking screw (24)
again to move the depth stop (20).
Checking the battery charge
level
LEDs
red, orange, green Battery charged
red, orange
red
1. Press the button (13) next to the
charge level indicator button (14) on
the battery (11).
The LEDs of the charge level indicator
show how much charge remains in the
battery.
2. Charge the battery (11) when only the
red LED on the charge level indicator
(14) is illuminated.
Charging the battery
See also the charger instruction manual.
Notes
• If warm, allow the battery to cool be-
fore charging.
• Do not expose the battery to direct sun-
light for long periods and do not place
it on a radiator (max. 50°C).
GB MT
Meaning
Battery partially
charged
Battery needs to be
charged
