a serious hazard to the user and result in
damage to the device. The operator or
user of the machine is responsible for any
accidents or personal injury and/or mater-
ial damage to third parties or their prop-
erty. The machine is intended to be used
by do-it-yourselfers. It was not designed
for heavy commercial use. The warranty
is void in the case of commercial use. The
manufacturer is not liable for damage
caused by improper use or incorrect oper-
ation.
The device is part of the X 20 V TEAM
series and can be operated with bat-
teries of the X 20 V TEAM series. Bat-
teries of the X 20 V TEAM series may
only be charged using chargers of the
X 20 V TEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material prop-
erly.
• Cordless Impact Driver
• Auxiliary handle
• Depth stop
• Storage case
• Translation of the original instructions
The rechargeable battery and
charger are not included in deliv-
ery.
Overview
The illustrations for the
device can be found on the
front fold-out page.
1 Drill chuck aperture
2 Keyless chuck
3 Torque adjustment ring
4 Holder for auxiliary handle
5 Function selection switch
6 Gear selector switch
7 Direction of rotation switch
8 Handle (Insulated gripping surface)
9 Belt clip
10 Battery holder
11 Battery
12 Battery release
13 Button (Charge level indicator)
14 Charge level indicator
15 LED work light
16 "Connected" indicator
17 On/Off switch
18 Loop (Auxiliary handle)
19 Auxiliary handle
20 Depth stop
21 Battery charger
22 Storage case
Fig. C
23 Handle (Auxiliary handle)
24 Locking screw of depth stop
Description of functions
Cordless impact drill screwdriver with two-
speed gearbox has 21 torque settings,
as well as one drill setting and one im-
pact setting, right/left rotation. The tool
is equipped with a keyless chuck and an
LED work light.
Please refer to the descriptions below for
information on how the operating ele-
ments work.
Technical data
Cordless Impact Driver
............................ PSBSAP 20-Li C3
Rated voltage U ............................. 20 V ⎓
Weight with battery (Smart PAPS 204)
........................................................ ≈ 2.1 kg
