Parkside Performance PSBSAP 20-Li C3 Traduction Des Instructions D'origine page 24

GB MT
No-load rotation speed n
– Level 1 ............................... 0–630 min
– Level 2 .............................0–2100 min
Impact rate
–Level 1 ............................. 0-10810 min
–Level 2 ............................. 0-36000 min
Max. torque .................................... 64 Nm
Chuck capacity ............................. ≤13 mm
Max. drilling diameter
–wood ............................................. 68 mm
–Concrete ........................................16 mm
–steel ............................................... 13 mm
Protection type .....................................IPX0
Idle
Sound pressure level (L
...................................... 80.9 dB; K
Sound power level (L
..................................... 88.9 dB; K
Impact drilling
Sound pressure level (L
...................................... 98.3 dB; K
Sound power level (L
...................................106.3 dB; K
Vibration Drilling (a
h,D
–Main handle ... 3.280 m/s²; K=1.5 m/s²
–Auxiliary handle
............................ 4.636 m/s²; K=1.5 m/s²
Vibration Impact drilling (a
–Main handle .13,283 m/s²; K=1.5 m/s²
–Auxiliary handle
............................ 7.645 m/s²; K=1.5 m/s²
Battery ................................................. Li-Ion
Temperature ................................... ≤50 °C
– Charging ................................4 – 40 °C
– Operation ......................... −20 – 50 °C
– Storage .................................. 0 – 45 °C
PARKSIDE Performance Smart battery
Smart PAPS 204 A1/Smart PAPS 208 A1
– frequency band .... 2400–2483.5 MHz
– transmitted power ................... ≤ 20 dBm
24
0
−1
−1
−1
−1
)
pA
=5 dB
pA
)
WA
=5 dB
WA
)
pA
=5 dB
pA
)
WA
=5 dB
WA
)
)
h,ID
Levels of noise and vibration were determ-
ined according to the standards and regu-
lations in the declaration of conformity.
The specified total vibration value and the
stated noise emission value have been
measured according to a standardised
test method and can be used to compare
one power tool with another. The specified
total vibration value and the stated spe-
cified noise emission value can also be
used for a provisional assessment of the
load.
WARNING! The vibration and noise
emissions may deviate from the specified
values during actual use of the power tool,
depending on how the power tool is be-
ing used. Try to keep the exposure to vi-
brations as low as possible. An example
of a measure to reduce vibration exposure
is limiting the working hours. All parts of
the operating cycle have to be considered
while doing so (for example, times when
the power tool is switched off and times
when it is switched on but running without
any load).
Charging time
The device is part of the X 20 V TEAM
series and can be operated with bat-
teries of the X 20 V TEAM series. Bat-
teries of the X 20 V TEAM series may
only be charged using chargers of the
X 20 V TEAM series.
We recommend that you operate
this appliance with the following bat-
teries only: PAP 20 B1, PAP 20 B3,
Smart PAPS 204 A1, Smart PAPS 208 A1
We recommend charging these batteries
with the following chargers: PLG 20 A3,
PLG 20 A4, PLG 20 C1, PLG 20 C2,
PLG 20 C3, PLG 201 A1, PDSLG 20 A1,
PDSLG 20 B1, Smart PLGS 2012 A1
Rechargeable battery and charger tech-
nical data: See separate manual.
