Assembly
1. Align the arrow on the spray gun with the "unlock"
symbol on the turbine.
2. Insert and twist the spray gun into the turbine toward the
"lock" symbol on the turbine. The tab below the trigger
will lock the two pieces into place.
Aligning the Suction Tube
If you are going to be spraying in a downward
direction, the angled end of the suction tube should be
pointing toward the front of the gun.
If you are going to be spraying in an upward direction,
the angled end of the suction tube should be pointing
toward the rear of the gun.
By pointing the suction tube in the proper direction,
you will not have to refill the container as often.
IMPORTANT: Never tip the sprayer at more than a 45°
angle. Material could get into the turbine and damage the
sprayer.
English
Setup

Material Preparation

Before spraying, the material being used may need
to be thinned with the proper solvent as specified by
the material manufacturer. Never exceed the thinning
advice given by the coating manufacturer.
Do not use materials with a flashpoint below 70°F
(21°C). Follow the instructions below.
1. Stir the spraying material thoroughly before measuring
viscosity.
2. Dip the viscosity test cup completely into the spraying
material.
3. Hold the test cup up and measure the time in seconds
until the liquid empties out. This time is referred to
below as Runout Time.
Material
1) Oil enamel
2) Oil based primer
3) Oil stain
4) Clear sealer
5) Polyurethane
6) Varnish
Material flash point must be 70°F (21°C) or
higher.
Fill Container
1. Unscrew the cup from the spray gun.
2. After the material has been properly thinned and
strained, fill the container to the top of the neck.
3. Carefully screw the cup back onto the spray gun.
4
Thinning Chart
Runout Time
No thinning required
No thinning required
No thinning required
25-40
30-45
20-50
