36. Over buck
37. Log supported both ends
38. Bucking a log
39. Stand on uphill side when cutting because log may
roll
40. Battery pack
41. Battery latch button
42. Charger
43. Charger cable
ASSEMBLY
This chain saw does not require assembly, but user should
know how to assemble the guide bar and saw chain.
Check the chain tensioning and add oil as described later
in this manual before each operation.
ASSEMBLING THE GUIDE BAR AND SAW CHAIN
See ¿ gure 2 - 7
Make sure remove the battery pack from the unit. Wear
protective gloves.
„ Unscrew the sprocket cover tighten knob (item 15) and
remove the sprocket cover.
„ The saw chain should face in the direction of chain
rotation. If they face backwards, turn the loop over.
„ Place the chain drive links into the bar groove.
„ Position the chain so there is a loop at the back of
the bar.
„ Hold the chain in position on the bar and place the
loop around the sprocket and make sure it is correctly
mounted. Make sure the bar hole fits well with bolt
(item 16) for saw chain tension.
„ Replace the sprocket cover, turn the chain tension
adjust knob (item 13) clockwise until the saw chain
is properly tensioned. The guide bar must then be
pushed upwards, check chain tension again, do not
tension the chain too tight.
„ After the chain is well-tensioned, tighten the knob
(item 15) again.
Note: The saw chain is properly tensioned if, in the middle
of the guide bar, it can be lifted 3mm to 4mm from the
edge of the guide bar. Start the saw again with a new saw
chain, allowing it to run-in for 2~3 minutes.
WARNING
After the run-in time, check the chain tension and re-
tighten the chain if necessary.
RCS36-23lgs manual.indd 17 RCS36-23lgs manual.indd 17
PT NL SV DA NO FI
English (original instructions)
HU CS RU RO PL SL
OPERATION
For complete charging instructions, refer to the
Operator's Manuals for your Ryobi battery pack and
charger models.
NOTE: To avoid serious personal injury, always remove
the battery pack and keep hands clear of the lock-out
button when carrying or transporting the tool.
BEFORE EACH USE CHECKING THE CHAIN TENSION
See ¿ gure 2
WARNING
Remove the battery pack from the chain saw before
checking the chain tension or making adjustments to
the chain. Wear protective gloves while touching the
chain, bar or areas around the chain.
„ Pull the chain in the middle of the lower side of the
bar away from the bar. The gap between the cutter in
the chain and the bar should be between 3mm - 4mm.
„ If you need to adjust the chain tension, please refer to
the section "ADJUSTING THE CHAIN TENSION" later
in this manual.
TO INSTALL BATTERY PACK
See Figure 2.
„ Place the battery pack in the chain saw. Align raised
ribs on battery pack with grooves in the chain saw's
battery port.
„ Make sure the latch on bottom of the battery
pack snaps in place and that battery pack is fully
seated and secure in the chain saw before beginning
operation.
TO REMOVE BATTERY PACK
See Figure 2.
„ Release the trigger to stop the chain saw.
„ Press and hold the battery latch button at the bottom
of the battery pack.
„ Remove battery pack from the chain saw.
CHECKING THE CHAIN LUBRICANT
See ¿ gure 1
„ Check the amount of oil in the chain saw by looking at
the oil level gauge (item 7). If the oil level is low, follow
the steps shown in section "ADDING CHAIN & BAR
LUBRICANT" of this manual.
WARNING
Check the chain tension before each use of the saw.
17
