4.4

Technical data

Parameter
General specifications
Dimensions housing
(W x H x D)
Weight
Housing material
Colour
Operating temperature range
Ambient
Storage
Max. humidity
Supply voltage
Nominal voltage
Nominal power (base module
only)
Mains fuse
Relay load
Permissible cable type
The following components may be connected to one product
Controller modules sextuple
Controller module dual
Total number of control circuits Max. 18
Total number of thermostatic
actuators
Electrical safety
Protection class (EN 60730-1) II
Degree of protection
(EN 60529)
Table 4-1: Technical specifications base module
Product description
RoCon UFH
Base module RoCon UFH-BM
122 mm x 92 mm x 45 mm
215 g
PC/ABS
Light grey, similar to RAL 7047
-20 °C ... +60 °C
-20 °C ... +60 °C
Non-condensing
AC 230 V, 50 Hz to 60 Hz
1 VA
T 10 A
Max. 230 V, max. 2 A, power factor > 0.6
H03 VV-H2-F 2 x 0.75 mm²
Max. 3
Max. 9
Max. 72 (see table 4-6)
IP 20
