Barrette rdi FINYL LINE Mode D'emploi page 8

2.
Pre-drill
bracket at the determined angle (Fig. 4).
3.
Cut railing to desired length. Place bracket on
each end of top and bottom rails (Fig. 5).
4.
Mark four screw hole locations on each bracket.
Set rail section aside, then pre-drill
holes in posts at each mark (Fig. 6).
Attach each top rail bracket with four #10 x 2"
5.
screws (Fig. 7). Attach each bottom rail bracket
with four #10 x
Pre-drill one
6.
and aluminum insert for each side of top rail
brackets only. Fasten with #10 x 1" flat head
screws (Fig. 8).
Add two screw covers for both top and bottom
7.
brackets and add two screw caps for each top
rail bracket (Fig. 9).
8
⁄ " diameter holes in base, then fasten
1
8
⁄ " screws.
11
2
⁄ " diameter hole through top rail
1
8
Fig. 7
⁄ " diameter
1
8
Fig. 8
Fig. 4
Fig. 5
Fig. 6
Rail
Baluster
Fig. 9
