8.2
Liste des pièces
N°
Désignation (ENG)
1
Main frame
2
Rear stabilizer
3
Adjustable round wheel
4
Front stabilizer
5
Cover of front stabilizer
6
Allen bolt
7
Bolt
7A
Bolt
8
Curved washer
9
Spring washer
10L
Left middle supporting cover
10R
Right middle supporting cover
11
Upper decorative cover
12
Rear cover
13
Seat post
14
Middle cable for quick button
15
Bolt
16
Flat washer
17
Handlebar post
18
Handlepulse cable
19
Support of bottler holder
20
Bottle holder
21
Bearing
22
Waved washer
23
Cross screw
24
C ring
25
Screw
26
Crank axle
27
Pulley wheel
28
Nylon nut
29
Bolt
30
Belt
42
Référence pièce fab.
744G1-3-1000-BA0
744S0-3-2112-BA1
76100-6-2174-B0
744S0-3-2100-BA0
734S0-6-2186-B0
50308-5-0040-F3
50108-5-0070-F4
50108-5-0110-F5
55108-3-2215-FA
55108-2-1520-FA
744S0-6-4551-B0
744S0-6-4552-B0
744S0-6-4520-B0
734S0-6-4514-B20
744S0-3-2200-BA2
744S0-6-2543-00
50108-5-0015-F0
55108-1-1612-FA
744S0-3-2000-BA1
744S0-6-2479-00
744S0-6-2292-B0
26100-6-1578-B0
58006-6-1042-00
55120-5-2705-DA
54203-2-0030-F0
55519-1-2312-DA
54203-2-0012-F0
734S0-3-2903-00
58008-6-1037-D0
55206-1-2006-FA
50106-5-0015-C0
58004-6-1113-00
Spécification
Nbre
1
1
D50*M10*1.5
4
1
600*190.2*79.4
2
M8*1.25*40L
2
M8*1.25*70L
4
M8*1.25*110L
4
D22xD8.5x1.5T
4
D15.4xD8.2x2T
12
366*79.4*118.9
1
366*76.1*118.9
1
629.3*170.6*114
1
191.9*172.1*138.4
1
1
550L
2
M8*1.25*15L
4
D16*D8.5*1.2T
29
1
2400L
2
168.6*168.6*45
2
D134*115
2
#6004-2RS(C0) (SKF)
2
D27*D20.3*0.5T
1
M3*0.5*30L
4
D22.5*D18.5*1.2T
2
M3*0.5*12L
2
1
D260*25*3T
1
M6*1.0*6T
6
M6x1.0x15L
4
440 PJ8
1
RB10.5
