4. Operations

4.1 Connection

1) Turn the ignition off.
2) Locate the vehicle's 16-pin Data Link Connector (DLC).
3) Plug the OBDII cable into the vehicle's DLC.
4) Turn the ignition on. Engine can be off or running.
] button to enter Main Menu as following figure 4-1:
5) Press [
CAUTION: Don't connect or disconnect any test equipment with ignition on or
engine running.

4.2 How to diagnose

Select [Diagnostic] in Main Menu and press [
Monitor Status interface as following figure 4-2:
Creader V+ English User's Manual
Figure 4-1
], the screen will display
Figure 4-2
