Simons Voss Technologies MK.Z4.PL Guide Abrégé page 33

Padlock (MK./SI.)Z4.PL
Recessed grip ring
8 Battery replacement (Passive)
EN
Batteries
Inside Knob
SC version
1. Place the installation/battery key on the knob in
such a way that its two teeth lock into the openings
in the locking disc; If necessary, turn the knob until
both teeth engage into the knob. Important: the
battery/installation key must be placed flat on the
inside front surface of the recessed grip ring to en-
sure that the installation tool can engage into the
locking disc.
2. Hold the knob firmly and carefully turn the battery/
installation key about 30° in a clockwise direction
(until you hear a click).
3. Remove battery/installation key from the knob.
4. Push recessed grip ring backwards towards the
padlock, so that it comes away from the thumb-
turn.
8. Battery replacement (Passive)
Markings
SC version
33 / 136
