Process transmitter
8. PC operating software
An operating manual for the PC operating software can be
found on the programme installation medium.
9. Technical data
Unit function
General details
Process
Application
transmitter
easurement
peration and
principle
system
construction
easurement
system
Input types
Input
easurement
range
76
Process transmitter for DIN top hat rail mounting.
Dependent on the unit version the measured analogue
input signal is displayed on a 5 digit display. The
analogue output transmits the displayed value as either a
current or voltage. Two presettable alarm set points
monitor the measured input for infringements on the
preset conditions and also control the two output relays.
The analogue signal connected is digitalised, analysed
and indicated in the display. A digital/analogue convertor
creates a propotional current or voltage signal that is
available at the output terminals for additional peripheral
equipment.
icrocontroller controlled measurement system with LC
display, analogue input, analogue output, alarm set point
relays and loop power supply.
Voltage, current, resistive thermometer (RTD),
potentiometer (R), thermocouple (TC)
Voltage: +/-100 mV;
+/-10 V;
Ri: 1
Ω
Current: 0/4...20 mA; max. current +/-150 mA
Ri: 10
Ω
RTD: Pt100: -200°...+850°C (DIN EN60751)
Ni100: -60°...+180°C (DIN 43760)
Pt500: -200°...+850°C (DIN EN60751)
Pt1000: -200°...+850°C (DIN EN60751)
Sensor current: approx. 250 µA, 2-, 3-, 4-wire
cable compensation up to 40
R: 0...4000
Ω
Sensor current: approx. 250 µA, 2-, 3-, 4-wire
cable compensation up to 40
TC: Type T:-270... +400 °C Type B:
Type J: -210...+1200 °C Type N: -270...+1300 °C
Type K:-200...+1372 °C Type U: -200... +600 °C
Type R: -50...+1800 °C Type L: -200... +900 °C
Type S: 0...+1800 °C Type W3: 0...+2315 °C
Type T, J, K, R, S, B, N to DIN EN60584;
Type U, L to DIN 43710;
Type W3, W5 to AST E988-96
max.. votlage: +/-5 V
(without damage): +/-50 V
(without damage)
Ω
Ω
0...+1820 °C
Type W5: 0...+2315 °C
