arameter
* Wiring type
Type of wiring when using
RTDs
* Cable resistance
Cable resistance on
RTDs
Curve
On current/voltage input
signals enter the
connection between the
sensor signal and the
value to be displayed
On temperature inputs the
engineering units for the
display are indicated
Signal damping
τ
Filter constant
in sec
for damping the input
signal
* Sensor decimal point
Number of decimal points
on sensor scale
* Sensor scale 0%
Sensor measurement
range
* Sensor scale 100%
Sensor measurement
range
Setting up selections
WIRED
2-wire, 3-wire, 4-wire
WREST
Value:
0 to 99,9
CURVE
* Current/voltage input signal:
LINAR
linear input
signal
5QRT
Square root of a
squared input signal
TABLE
Presettable
linearisation table
* Temperature input:
°C
Degrees Celsius
°F
Degrees Fahrenheit
DAMP
Value:
0 to 99
(low pass)
5c DP
Selection range:
0 to 4 decimal points
Sc LO
Values:
-19999 to 99999
Sc HI
Values:
-19999 to 99999
Process transmitter
Default
Actual
settings
setting
2 WRD
0,0
LINAR
°C
0
999,9
0,0
100,0
57
