Process transmitter
5.6 Linearisation table
The following addresses are only displayed in the setting up
menu if linearisation of the input signal has been selected.
Address
arameter
* Number of points
Enter of the number of
linearisation points are to
be allocated
The number of points can
be inceased at a later
time
The first and last points are automatically set by the unit and are allocated the values
of sensor scale 0% (
SC H1
(
) to display value 100% (
* Delete all
points
All linearisation points are
deleted to allow input of a
new linearisation curve
* Display all
points
In order to simplify
operation and setting up
it is advisable to blend
out all linearisation points
after they have been set
up
The contents of the
points remains
unchanged and the
display can be switched
on again at any time
66
is set to
CURVE
TABLE
Setting up selections
COUNT
Number:
2 to 32
SC LO
) to display value 0% (
DI HI ).
DEL
YES
All linearisation points
are deleted after
acknowledgement
NO
All linearisation points
remain unchanged
LSHOW
YES
All linearisation points
are indicted in the
display
NO
The linearisation
points are blended
out
.
Default
settings
2
DI LO
) and sensor scale 100%
NO
YES
TABLE
Actual
setting
