12 Device information

1 Type and order code
2 Design
2.1 Model
2.2 Thermal energy meter
2.3 Installation location / degree of protection according to EN 60 529
2.4 Water in device protected against freezing
2.5 Performance levels
3 Operating limits
3.1 Heating water flow / return
3.2 Cold water (heat source)
4 Performance data / flow rate
4.1 Heating water flow rate with an internal pressure differential of
Minimum heating water flow rate
4.2 Cold water flow rate at an interal pressure differential of
3
4.3 Heat output / COP
4.4 Sound power level
4.5 Sound pressure level at a distance of 1m
5 Dimensions; weight and filling quantities
5.1 Device dimensions without connections
5.2 Device connections for heating
5.3 Device connections for heat source
5.4 Weight of the transportable unit(s) incl. packaging
5.5 Refrigerant; total filling weight0
5.6 Lubricant; total filling quantity
6 Electrical connection
6.1 Load voltage; Fuse protection
6.2 Control voltage; Fuse protection
6.3 Starting current with soft starter
6.4 Nominal power consumption W10 / W35 / max. consumption
6.5 Nominal current W10/W35 / cos ϕ
6.6 Power consumption of compressor protection
(per compressor)
7 Complies with the European safety regulations
8 Additional model features
8.1 Max. operating overpressure (heat source/heat sink)
1. The heat circulating pump and the heat pump manager must always be ready for operation.
2. The given well water flow rate is identical for all operating points.
3. These data indicate the size and capacity of the system according to EN 255 and EN 14511 (5K at W10). For an analysis of the economic and energy efficiency of the system,
both the bivalence point and the regulation should be taken into consideration. These specifications can only be achieved with clean heat exchangers. Information on mainte-
nance, start-up and operation can be found in the respective sections of the installation and operating instructions. The specified values, e.g. W10 / W55, have the following
meaning: Heat source temperature 10 °C and heating water flow temperature 55 °C..
4. The temperature spread of 5K is based on the standard value of W10 / W35 in operation with 2 compressors.
5. Operation with 2 compressors.
6. Operation with 1 compressor.
7. The specified sound pressure level corresponds to the operating noise of the heat pump in heating operation with a flow temperature of 35°C. The specified sound pressure level
represents the free sound area level. The measured value can deviate by up to 16 dB(A), depending on the installation location.
8. Please note that additional space is required for pipe connections, operation and maintenance.
9. Double nipples matching the connection sized are included in the scope of supply
10.See CE certificate of conformity.
