Temperature probe cover
Display screen
Power on/off key
Battery cover
Figure 3.11A the infrared temperature probe
1. Connect the infrared temperature probe to the connector on the front side of device marked "TEMP".
2. When the probe screen shows as figure 3.11B and the temperature unit "℃" is blinking, the user can begin
to take the measurement.
3. Insert the tip of the temperature probe into the earhole and press the measuring key to start the measurement.
A short beep means the measurement has finished and the result will be displayed on the both probe and the
monitor screen .
Note: When unplugging the probe, be sure to hold the head of the connector and pull it out.

3.4.5 Loading printer paper (if printer is installed)

Operation procedures for loading printer paper:
1. To open the printer cover, press two thumbs firmly on both "OPEN" notches.
2. Move the tab of the left rubber roller lock 90°upwards to unlock it, refer to the following figure
with mark ①.
3. Cut one end of the paper into a triangle, and load the paper from the underside of the rubber roller.
4. Turn the roller clockwise to roll the paper rolled, and put the paper roll into the compartment.
5. Pull the paper out of the paper slot on the shield.
6. Move the tab of the rubber roller lock 90° downwards to lock it.
7. Put the shield back in position and secure it.
Operation procedures for taking out printer paper roll:
Steps 1~2: Same as above.
Steps 3. Roll the loading roller anti-clockwise and pull the paper out.
Steps 4~5: As steps 6~7 above.
Measuring key
17
The display screen
Figure 3.11 B
