1.4.2 Technical data pulse inputs
Pulse input class
Connecting cable length
Voltage supply
Source current
High level input threshold
Low level input threshold
Pull-up resistor
Pulse length
Pulse frequency
1.4.3 Possible combinations of the different input (class IB) and output (class OA) devices
Class OA
Class OB
Class OC
Class OD
Class OE
1.4.4 Setting up the three additional pulse inputs
The optional pulse inputs 1 + 2 + 3 for external meters can be set up using the "Device Monitor" configuration
software. You can configure serial number, manufacturer, version (0 ... 255), medium code, input pulse value, unit
and starting value of the external meters.
1.4.5 Set-up possibilities
Pulse value
1
2,5
10
25
100
250
1000
Installation notes for pulse inputs:
It is important that the pulse cables not be affected by (or exposed to) an external voltage!
Check the polarity of pulse generators with "open collector" outputs.
The cable wires must not touch each other during installation, otherwise pulses will be counted in the instrument.
When setting up the meter it may be necessary to adjust the meter reading of the instruments connected and the
pulse value using the "Device Monitor" software.
For transmitting the values of the pulse inputs via radio, transmission must be set using the "Device Monitor"
software, if the meters were not already ordered with the transmission of these values set.
Select the menu item „Parameterization of the module" in the software. Set the radio transmission in the menu
item „Transmission of values for the pulse inputs". (The transmission of these values via M-Bus is always set in the
factory setting.)
1.4.6 Pin assignments 6-wire cable
Color
Pink
Grey
Yellow
Green
Brown
White
Page 45 of 73 Article no.: 1080621016
IB according to EN 1434-2:2016
1 m
+ 3 V DC
= 1,5 µA
U ≥ 2 V
U ≤ 0,5 V
2 MΩ
≥ 100 ms
≤ 5 Hz
Class IA Class IB
yes yes
yes no
no yes
no no
no no
Units
liters / kWh / pulse without unit
liters / kWh / pulse without unit
liters / kWh / pulse without unit
liters / kWh / pulse without unit
liters / kWh / pulse without unit
liters / kWh / pulse without unit
liters / kWh / pulse without unit
Connection
IE1+
IE1┴
IE2+
IE2┴
IE3+
IE3┴
Class IC
no
no
yes
yes
no
2022_04_05 Subject to technical change! Errors excepted.
Class ID Class IE
yes no
yes yes
no no
no no
no yes
