Code Explanation
SPECIAL CYCLE AMOUNT TO START*
3.06
3.06 Represents the amount of Coins or Gen 1 Debit
Pulses required to start a Special Cycle. See Value
of Coin 1 setting.
■ PD Models Factory Default is 606 (Requires
6 Coins or Gen 1 Debit Pulses).
■ PR Models Factory Default is 600 (Free Vend).
■ Use Heavy Duty Keypad to adjust from 0 to 39.
■ Press the NORMAL button once to advance to
next code.
SPECIAL DRY TIME*
4.05
4.05 Represents the number of minutes per coin
(Coins or Gen 1 Debit Pulses).
■ Factory default of 5 minutes per coin.
Example: 6 coins x 5 minutes = 30 minutes.
■ By pressing the HEAVY DUTY button, the value
can be adjusted from 1-75 maximum minutes.
■ Press the NORMAL button once to advance to
next code.
5.00 TIME-OF-DAY CLOCK, MINUTES
5.00 This is the TIME-OF-DAY CLOCK, minute setting;
select 0-59 minutes by pressing the HEAVY DUTY
button.
■ Press the NORMAL button once to advance to
next code.
TIME-OF-DAY CLOCK, HOURS
6.00
NOTE: Uses military time or 24 hour clock.
6.00 This is the TIME-OF-DAY CLOCK, hour setting;
select 0-23 hours by pressing the HEAVY DUTY
button.
■ Press the NORMAL button once to advance to
next code.
SPECIAL PRICE START HOUR*
7. 00
NOTE: Uses military time or 24 hour clock.
7. 00 This is the start hour; 0–23 hours.
■ Select START HOUR by pressing the HEAVY
DUTY button.
Press the NORMAL button once to advance to
■
next code.
SPECIAL PRICE STOP HOUR*
8. 00
NOTE: Uses military time or 24 hour clock.
8. 00 This is the stop hour; 0–23 hours.
Select STOP HOUR by pressing the HEAVY
■
DUTY button.
■ Press the NORMAL button once to advance to
next code.
Code Explanation
SPECIAL PRICE DAY*
9. 10
9. 10 This represents the day of the week and whether
special pricing is selected for that day. A number
followed by "0" indicates no selection that particular
day (9.10). A number followed by an "S" indicates
selected for that day (9.1S). Days of the week (1–7)
are selected by pressing the HEAVY DUTY button.
Press the DELICATES button once to select special
pricing for each day chosen.
When exiting setup code "9," the display must show the
current day of week:
DISPLAY DAY OF WEEK
10 Day 1 = Sunday
20 Day 2 = Monday
30 Day 3 = Tuesday
40 Day 4 = Wednesday
50 Day 5 = Thursday
60 Day 6 = Friday
70 Day 7 = Saturday
Press the NORMAL button once to advance to next code.
■
A. 00
VAULT VIEWING OPTION
This option is either NOT SELECTED "OFF" or
SELECTED "ON."
A. 00 Not Selected "OFF."
A. SC Selected "ON."
■ Press the DELICATES button once to change
this selection. When selected, the money and/or
cycle counts will be viewable (if counter option(s)
is selected) when the coin box is removed.
Press the NORMAL button once to advance to
■
next code.
VALUE OF COIN 1 OR GEN 1 DEBIT PULSES*
b. 05
b. 05 This represents the value of Coin 1 in number of
$0.05 increments of the larger coin value. 5 x $0.05
= $0.25.
■ By pressing the HEAVY DUTY keypad, there
is the option of 1–199 for the quantity of $0.05
increments.
■ This is also the value of a one Debit Pulse if using
a Gen 1 Debit device.
■ Press the NORMAL button once to advance to
next code.
CODE (selected)
1S
2S
3S
4S
5S
6S
7S
*
